A digital multimeter (DMM) that is made to be mounted on a control panel or an equipment enclosure is referred to as a panel mount multifunction digital meter. These meters are frequently utilized in industrial settings, automation systems, power distribution panels, and a number of other applications where electrical readings must be continuously tracked and presented.

Key features of a panel mount multifunction digital meter may include:
1. Form Factor | 2. Multiple Measurement Functions | 3. Accuracy and Resolution | 4. Display | 5. User Interface | 6. Communication Interfaces | 7. Environmental Considerations

Show All Items



Sort By:

Reset



Item Code

Product Detail

Unit

QTY

Unit Price

T. Price

Add to Enquiry
Multi Function Digital Meter ZIEGLER EMD 96

Multi Function Digital Meter ZIEGLER EMD 96
 Type: Multifunction meter , Brand: Ziegler

Pcs

AED 503.50

AED 503.50

Ziegler Delta Energy measures important electrical parameters in 3 phase 4 Wire and 3 phase 3 Wire Network & replaces the multiple analog panel meters. It measures electrical parameters like AC Voltage,AC Current, Frequency, Active, Reactive, Apparent Power Import & Export Energy & many more.

Salient Features

Fast & Easy Installation on panel with self clicking.

True RMS measurement. MODBUS (Rs485) Communication (optional).

Pulse/Limit Switch output (optional). 3 Line 4 Digits ultra bright LED Display (up to 9999).

On site Programmable CT/PT Ratios. User selectable CT Secondary 1A/5A.

User selectable PT Secondary from 100 VLL to 500 VLL. User selectable 3ph3wire / 3ph4wire / single phase Network.

Programmable Energy format & Energy rollover count.

Wide auxillary Power Supply which can accept any input between 40V – 300V AC/DC. Storage of MIN / MAX values.

Measurement & Display of RPM, Run hours, On hours, No. of interruption.

Products Features

On site programmable PT/CT ratios: It is possible to program primary of external potential Transformer (PT), primary of external Current Transformer (CT) on site via front panel keys by entering into Programming mode.

User selectable CT Secondary 5A/1A The secondary of external Current Transformer (CT) can be programmed on site to either 5A or 1A using front panel keys.

User selectable PT Secondary The secondary of external Potential Transformer (PT) can be programmed on site from 100VLL to 500VLL using front panel keys.User can set the display in auto scrolling mode or fixed screen mode using front panel keys.

Low back depth: The instrument has very low back depth (behind the panel) of less than 55 mm(Without output option).

Four function keys: Using the four function key, it is possible to go desired parameter screen instantly..

Demand Measurement Measures & Displays Current Demand, kVA Demand, kW Import Demand, kW Export Demand. Any of the parameters can be assigned to optional Limit switch.
