This EVlink Home product is a wall-mounted charging station for all electrical vehicles compliant with IEC61851-1 standard. The IP degree of protection is IP55. The IK degree of protection is IK10. The operating temperature is between -30°C and 50°C. The output type is a 5m attached cable with a T2 socket-outlet at the end, installed at the bottom and top centre of the station. The nominal output power is 11kW. It is supplied in three-phase (3P+N). The rated charging current is 16A under 400VAC at a 50Hz frequency with a tolerance of +/-10%. It can be used with a TN-S or TT earthing system. The charging station is easy to install (no special tools required). It is recommended for private use at home, installed in the garage for instance. The dimensions are (W) 282mm x (H) 409mm x (D) 148mm. Its product weight is 5.6kg. Its color is white (RAL9003). It is fitted with a built-in protection against residual direct current (RDC-DD as Residual Direct Current Detecting Device). There is no access control to use the charging station for loading an electrical vehicle. A red push-button is present in case of emergency stop. One LED is changing color between red, green and blue in order to indicate the loading status directly on the charging station. By complementing the charging station with the anti-tripping system, it benefits of the dynamic energy management. This one allows to adjust in real time the maximum power allocated to the charging electric vehicle, according to the consumption of the rest of loads in the house.
Range |
EVlink |
Product name |
EVlink Home |
Product or component type |
Charging station |
Poles description |
3P + N |
Mounting mode |
Wall-mounted |
Offer type |
Basic |
Max power |
11 kW 16 A 400 V |
Number of charge point |
1 |
Connection to the vehicle |
Attached cable T2 bottom and top centre of enclosure 5 m |
Quantity per set |
Set of 1 |
Complementary
rated supply voltage |
400 V AC 50 Hz +/- 10 % |
Earthing system |
TT
TN-S |
Number of inputs |
1 |
Input type |
Auxiliary for dynamic energy management |
Control type |
Red 1 emergency stop, function: 1 push-button |
Local signalling |
Red, green and blue 1 LED, function: status indication |
Protection type |
Earth-leakage protection |
Height |
409 mm |
Width |
282 mm |
Depth |
148 mm |
Net weight |
5.6 kg |
Colour |
White (RAL 9003) |
Standards |
EN 61851
IEC 61851-1
EN 61000-6-1
EN 61000-6-3 |
Product certifications |
CE
UKCA |
Maximum supply current |
16 A |
Environment
IP degree of protection |
IP55 conforming to EN/IEC 60529 |
IK degree of protection |
IK10 conforming to IEC 62262 |
Ambient air temperature for operation |
-30…50 °C |
Ambient air temperature for storage |
-40…85 °C |
Relative humidity |
5…95 % |
Operating altitude |
0...2000 m |
Packing Units
Unit Type of Package 1 |
PCE |
Number of Units in Package 1 |
1 |
Package 1 Height |
32.2 cm |
Package 1 Width |
40.0 cm |
Package 1 Length |
49.0 cm |
Package 1 Weight |
6.7 kg |
Unit Type of Package 2 |
P12 |
Number of Units in Package 2 |
8 |
Package 2 Height |
79.0 cm |
Package 2 Width |
80.0 cm |
Package 2 Length |
120.0 cm |
Package 2 Weight |
66.5 kg |
