Switch Disconnector BMSDW4

BRAND: ABB

Switch Disconnector / Isolator Reel Mount

Item Code: AMSG-3435

Categories : Isolator Reel Mount

Tags : Switch Disconnector Suppliers in Dubai, Switch Disconnector Suppliers in UAE

Cash on delivery available

Return allowed

Sort By:

SlNo	Item code	Product details	Unit	QTY	Unit price	T. price	Action
1	AMSG-3435-1	Switch Disconnector BMSDW4, Amps: 40 A, Pole: 4 Pole, Product Code: 1SYD674062R0040, Brand: ABB	Pcs		AED 44.85	AED 44.85
2	AMSG-3435-2	Switch Disconnector BMSDW4, Amps: 63 A, Pole: 4 Pole, Product Code: 1SYD674062R0063, Brand: ABB	Pcs		AED 47.15	AED 47.15

A switch disconnector, sometimes referred to as an isolater switch, is a crucial electrical tool used for emergency shutdowns, maintenance, and safety purposes. In addition to safeguarding people and property, it guarantees a safe break in the electrical circuit.

Important features:

Safe Isolation: For emergencies or maintenance, electrical circuits are completely disconnected.
Strong Construction: Using premium materials ensures dependability and longevity.
Simple Operation: Designed for seamless switching with a distinct ON/OFF indicator.
Broad Use: Fits well with commercial, residential, and industrial electrical systems.
Compliance and Safety: Adheres to global electrical safety regulations.

Click here > Catalogue

Category	Feature	Value
General Data	Standards	IEC/EN 60947-3
	Poles	2P, 3P, 4P
	Rated current In	40, 63 A
	Utilization category	AC-22A
	Rated voltage Ue	2P, 3P, 4P: 400 V AC
	Insulation voltage Ui	250V AC (Phase to Phase) 440 V AC (Phase to Ground)
	Rated frequency f	50/60 Hz
	Suitable for isolation	yes
	Rated conditional short-circuit current	10 kA in series with NH 00 ≤ 63 A gG
	Electrical endurance	le < 32>
	Rated impulse withstand voltage Uimp. (1.2/50μς)	4 kV (Test voltage 6.2kV at sea level, 5kV at 2000m)
	Dielectric test voltage	2 kV (50Hz, 1 min.)
	Max. power frequency recovery voltage (Umax)	2P, 3P, 4P: 457 V AC
	Min operating Voltage	12V AC
	Overvoltage Category	III
	Pollution degree	2
Mechanical Data	Housing	Insulation group II
	Toggle	Insulation group II, black, sealable
	Contact position indication	White Marking on toggle ('I' ON / 'O' OFF)
	Protection degree acc. to EN 60529	IP20, IP40 in enclosure with cover
	Mechanical endurance	le < 32>
	Tropicalisation acc. to IEC/EN 60068-2-30	Severity 2 Cyclic test with 55°C/90-96% and 25°C/95-100%
	Ambient temperature	-25 ... +55°C
	Storage temperature	-40 ... +70°C
	Housing	Insulation group II
Installation	Terminal	Cage terminal
	Cross-section of conductors (top/bottom) Solid, Stranded	35 mm⊃2;/35 mm⊃2;
	Flexible	25 mm⊃2;/25 mm⊃2;
	Cross-section of busbars (top/bottom)	10 mm⊃2;
	Busbars type	Pin and Fork Type Busbar provision
	Tightening Torque	2 Nm
	Screwdriver	No. 2 Pozidrive
	Mounting	On DIN rail 35 mm
	Mounting position	Any
	Supply	Any
	Cable Length	12.5mm
Dimensions and weight	Mounting dimensions acc. to DIN 43880	Mounting dimension 1
	Pole dimensions (H x D x W) (per pole)	88 x 69.2 x 17.5 mm
	Pole weight (per pole)	70gms
Approvals	CE Marking approved	Yes
	MoIAT ROHS Certification	Yes
