• Weekly programming on a digital time switch
• One channel
• App-based programming is feasible
• Secure transfer through an optional Time switch programs can only be transferred from the app to the time switch when the Bluetooth OBELISK top3 is inserted into the time switch for maximum manipulation security.
•  Top2 is completely compatible
• Spring terminals with DuoFix
•  Wire diameter: 0.5 mm2 to 2.5 mm2 for each conductor, with or without wire end sleeves.
•  Plug-in connection release button
•  Text-based display user advice
•  A fixed time and date
•  completely functional without a power source
•  56 memory addresses
•  OBELISK top2 memory card interface (PC programming)
•  insertable switching program 2.
•  Copying software
•  Program storage10 years of lithium battery power reserve
•  Zero-cross switching for high-speed switching and relay-saving

Delay On Make Timer – QD – 068 – SIGMA

UNI VAC 10MIN.ADJ

DIVERSIFIED: AC-800, ASC-600, ASC-601

GEMLINE: 1C310 1C213

Brand: SIGMA   Model: QD-068

Timers-LMAT ( Multi-Attempt to Start )

• Multi Attempt to Start
• Designed to limit the number of attempts an engine has to start before providing an alarm
• Selectable number of attempts (2-8)
• Multi-voltage (12 –48VAC/DC)
• Single time range (1 – 60s)
• 2 x SPDT Relay outputs
• 17.5mm wide, DIN Rail mount
• UL Listed

The timer is offered with two separate relays. When power is applied, the first relay (Attempts) will energise for the set “on” time delay period, then de-energise for the set “off” time delay period. This is classed as the “first attempt”. The same relay will continue to cycle on and off for the “number of attempts” set on the adjustment. If all the attempts are allowed to run, at the end of the last “on” time delay period, the first relay will de-energise and the second relay (Alarm) will energise and remain in this state. Power must be removed and re-applied to restart the function over again.

Timers-LEYD / A ( Star/ Delta Start )

• Star/Delta Start
• Selectable Dwell times (7)
• Multi-voltage (12 – 230VAC/DC)
• Multi-time range (0.1s – 100h)
• SPDT Relay output
• 17.5mm wide, DIN Rail mount
• UL Listed

When power is applied, the output relay remains de-energised for the set time delay period. After the delay has elapsed, the contacts “break” for the set Dwell time, then changeover to the energised state. Power must be removed and re-applied to restart the function over again.

SPECIFICATION:

• Timing function: Star/Delta Start
• Supply voltage:  12 – 230VAC/DC +/-15% (-10% if AC)
• Time delay: 0.1s – 100h
• Dwell time:  40, 60, 80, 100, 120, 140, 160ms
• Output: SPDT 6A @ 250V (AC1)
• Dimensions(mm): W:17.5 x H:89 x D:66.5
• Product standard(s): IEC 61812

Timers-LEDF ( True Delay Off )

• True Delay Off
• Single voltage
• Single time range
• SPDT Relay output
• 17.5mm wide, DIN Rail mount
• UL Listed

The output relay energises as soon as power is applied. When power is removed, the set time delay period commences and the relay will remain energised for this period. After the delay has elapsed, the relay de-energises. Power must be removed and re-applied to restart the function over again.

SPECIFICATION:

• Timing function: True Delay Off
• Supply voltage*:  24VAC/DC // 110VAC, 24VAC/DC // 230VAC +/-15%
• Time delay*: 0.5 – 10s, 2 – 60s, 0.5 – 10m
• Output: SPDT 8A @ 250V (AC1)
• Dimensions(mm): W:17.5 x H:89 x D:66.5
